Van Damme Smart Control Signal & DC Power Cable. Flexible PVC. 268-600-000

Van Damme Smart Control cables are primarily for use with common automation systems increasingly found in home and office environments. These systems run a screened twisted pair with an additional 2 wires for DC voltages used, for example, for powering remote programmable touch panels. For this range Van Damme have used a 22AWG AES/EBU 110 Ohm twisted pair as the data pair allowing additional applications for the cable such as DMX & power for lighting colour changers.

Available in both PVC and Low Smoke Zero Halogen (LSZH) versions. This listing is for the flexible PVC cable

Applications

• Control cabling for home automation systems
• DMX and power cables

Application Notes

• 110 Ohm AES/EBU pair will also carry digital and analogue audio, DMX, timecode and midi signals
• Available with LSZH jacket for installation
• Low Smoke Zero Halogen version uses SHF1 thermoplastic jacketing materials compliant with IEC 60092-360:2014 Electrical installations in Ships

Technical Info

Mechanical Specification (Data Pair)

• Conductor - 7 x 0.25 mm bare ultra-pure oxygen-free copper
• Conductor size - 7 x 0.25 mm, 0.34 mm2, AWG 22/7
• Insulation - Foam skin polyethylene, Red/Black
• Insulation diameter - 1.75 ± 0.10 mm
• Drain wire - 19 x 0.12 mm tinned ultra-pure oxygen-free copper
• Drain wire size - 19 x 0.12 mm, 0.22 mm2, AWG 24/19
• Screen - 24 µm Aluminium/Polyester Foil > 100% coverage

Power Elements

• Conductor size - 32 x 0.20 mm, 1.00 mm2, AWG 17
• Insulation - 268-600-000 PVC
• Insulation - 278-600-000 SHF1 LSZH thermoplastic polymer
• Colour code Brown, Blue

Overall construction

• Separator - Fleece tape
• Overall jacket - 268-600-000 Flexible PVC Composite
• Overall jacket - 278-600-000 SHF1 LSZH thermoplastic polymer
• Colour - Non-Metallised Pearl Blackberry RAL 4012
• Overall diameter - 7.40 ± 0.25 mm
• Bend radius - 15 x overall diameter

Operating temperature

268-600-000 - (-20 to +70 ⁰C)
278-600-000 - (-35 to +70 ⁰C)

Electrical Specification (Data pair)

• Resistance Conductor - < 59 Ohm/km
• Insulation - > 5000 MOhm/km
• Capacitance - Core to core 40 pF/m
• Core to screen - 80 pF/m
• Impedance - 1 -3 MHz 110 ± 20% Ohms
• Attenuation - 3 MHz 4.90 dB/100 m

Part Numbers and Description

• Part Number / Description / Max. Reel Length
• 268-600-000 / Smart Control Automation cable PVC / 500m
• 278-600-000 / Smart Control Automation cable LSZH / 500m

Standards and Compliance

• RoHS - 2011/65/EU Restriction of Hazardous Substances
• REACH - Registration, Evaluation, Authorisation and Restriction of Chemicals
• 278-600-000 only: IEC 60092-360:2014 Electrical Installations in ships - Sheathing materials for shipboard power and communication cables
• IEC 60332.1 Fire retardancy of a single cable
• IEC 60754.1 Amount of Halogen Gas Emissions
• IEC 60754.2 Degree of acidity of released gases
• IEC 61034.2 Measurement of smoke density
