REAN NYS224BG Mono TS Jack Socket. Black and Gold
£2.79
In stock
We have 159 items in stock!
SKU
JACKS_NYS224BG
Multibuy discounts calculated at checkout
- Buy 5 for £2.65 each and save 5%
- Buy 10 for £2.51 each and save 10%
- Buy 15 for £2.37 each and save 15%
- Buy 20 for £2.23 each and save 20%
Rean 1/4" TS Mono Jack featuring a long black diecast handle and gold contacts.
Technical Information
Product
Title - NYS224
Connection Type - Plug
Electrical
- Contact Resistance - ≤10mΩ
- Insulation Resistance - ≥200 MΩ(Initial)
- Dielectric Strength - 0.5 KVdc 50HZ
Mechanical
- Insertion and Withdrawal Force - ≤60N
- Lifetime - >1,000 Mating Cycles
Material
- Tip - Brass
- Inner - Steel
- Bushing - PA66+30%GF
- Insulation - PVC
- Sleeve - Brass
- Sleeve - Zinc
- Insulation - PA66+30%GF
- Soldering Contact - Brass
- Cable Clamp - Steel
- Housing - Zinc
- Tip - Nickel Plating
- Sleeve - Nickel Plating
- Sleeve - Nickel Plating
- Housing - Nickel Plating
- Inner - Zinc Plating
- Soldering Contact - Zinc Plating
- Cable Clamp - Zinc Plating
| Delivery Speed | Next Day delivery available if 'In Stock' |
|---|---|
| Mounting Method | Cable Mount - Solder |
| Series Range Name | Classic Style Jacks |
| Contact Material | Gold Plated |
| Number of Contacts | 2 Pole |
| Pack Quantity | Pack of 1 |
| Manufacturer URL | Download Data Sheet |
| Data Sheet URL | Download Data Sheet |
